Silicone Straight Tube

TKL NO.
TKL56146892, TKL56155247, TKL56114060, TKL56114142, TKL561143250, TKL56115300, TKL561143523, TKL561143524, TKL5611540060, TKL5611540075, TKL5611540080, TKL56116300, TKL56116350, TKL56116400, TKL56116460, TKL56175638, TKL56175716
OE NO.
561-46892, 561-55247, 561-14060, 561-14142, 561-143250, 561-15300, 561-143523, 561-143524, 561-1540060, 561-1540075, 561-1540080, 561-16300, 561-16350, 561-16400, 561-16460, 561-75638, 561-75716

Specification of TKL56146892 Silicone Straight Tube

TKL NO.	OE NO.	DESCRIPTION
TKL NO.	OE NO.	Size/mm	Size/inch	color	layer/polyester	thickness
TKL56146892	561-46892	ID44mm, L82.5mm	length 3 1/4" ID 1 3/4" smooth	BLUE	4	5mm
TKL56155247	561-55247	ID 102mm, L 622mm	ID 4"/ L 21.5"	BLUE	4	5mm
TKL56114060	561-14060	ID1 89mm, ID2 76mm L 127mm	length 5" ID1 3.5" ID2 3"	ORANGE-RED	4	5mm
TKL56114142	561-14142	ID76mm, L 111mm	length 4 3/8" ID 3"	ORANGE-RED	4	5mm
TKL561143250	561-143250	ID1 76mm, ID2 63mm L140mm	length 5.5",ID1 3 ", ID2 2 1/2"	ORANGE-RED	4	5mm
TKL56115300	561-15300	ID76mm, L152mm	length 6" ID 3"	ORANGE-RED	4	5mm
TKL561143523	561-143523	ID 89mm-63.5mm, L 138mm	I.D.: 3.5"-2.5" Length: 5.438" smooth	ORANGE-RED	4	5mm
TKL561143524	561-143524	ID 102mm-79mm, L 124.5mm	I.D.: 3.5"-3.125", Length: 4.900" smooth	ORANGE-RED	4	5mm
TKL5611540060	561-1540060	ID102mm, L 152mm	length 6" ID 4" smooth	ORANGE	4	5mm
TKL5611540075	561-1540075	ID102mm, L 190mm	length 4" smooth	ORANGE	4	5mm
TKL5611540080	561-1540080	ID 102mm, L203mm	length 7 1/2" ID 4"/ L 8" smooth	ORANGE	4	5mm
TKL56116300	561-16300	ID76mm, L152mm	length 6" ID 3"	BLUE	4	5mm
TKL56116350	561-16350	ID89mm, L152mm	length 6" ID 3.5"	BLUE	4	5mm
TKL56116400	561-16400	ID102mm, L152mm	length 6" ID 4"	BLUE	4	5mm
TKL56116460	561-16460	ID102mm, L165mm	length 6 1/2" ID 4" smooth	BLUE	4	5mm
TKL56175638	561-75638	ID 63mm, L225mm	length 8.875" ID 2 1/2"	BLUE	4	5mm
TKL56175716	561-75716	ID 102mm, L152mm	ID 4"/ L 6"	ORANGE	4	5mm
