Male45°Swivel Elbow

TKL NO.
TKLAQ54-D0TS-4X2, TKLAQ54-DOTS-4X4, TKLAQ54-DOTS-6X2, TKLAQ54-DOTS-6X4, TKLAQ54-DOTS-6X6, TKLAQ54-DOTS-8X4, TKLAQ54-DOTS-8X6, TKLAQ54-DOTS-8X8, TKLAQ54, DOTS-10X8
OE NO.
179PMT-4-2, 179PMT-4-4, 179PMT-6-2, 179PMT-6-4, 179PMT-6-6, 179PMT-8-4, 179PMT-8-6, 179PMT-8-8

Specification of TKLAQ54-D0TS-4X2 Male45°Swivel Elbow

TKL NO.	OE NO.					DESCRIPTION
TKL NO.	PARKER	EATON	ALKON	MAF	GATES	Tube O.D. * Female NPTF
TKLAQ54-D0TS-4X2	179PMT-4-2	1880x4S	AQ54-D0TS-4X2	540402S		1/4 * 1/8
TKLAQ54-DOTS-4X4	179PMT-4-4	1880x4x4S	AQ54-DOTS-4X4	540404S		1/4 * 1/4
TKLAQ54-DOTS-6X2	179PMT-6-2	1880x6x2S	AQ54-DOTS-6X2	540602S		3/8 * 1/8
TKLAQ54-DOTS-6X4	179PMT-6-4	1880x6S	AQ54-DOTS-6X4	540604S		3/8 * 1/4
TKLAQ54-DOTS-6X6	179PMT-6-6	1880x6x6S	AQ54-DOTS-6X6	540606S		3/8 * 3/8
TKLAQ54-DOTS-8X4	179PMT-8-4	1880x8x4S	AQ54-DOTS-8X4	540804S		1/2 * 1/4
TKLAQ54-DOTS-8X6	179PMT-8-6	1880x8S	AQ54-DOTS-8X6	540806S		1/2 * 3/8
TKLAQ54-DOTS-8X8	179PMT-8-8	1880x8x8S	AQ54-DOTS-8X8	540808S		1/2 * 1/2
TKLAQ54-DOTS-10X8			AQ54-DOTS-10X8	541008S		5/8 * 1/2
