Tie Rod End

TKL NO.
TKL187LR, TKL2090-91LR, TKL3274-75LR, TKL3476-77LR, TKL373LR, TKL411LR, TKL423LR, TKL844LR
REF NO.
ES187LR, ES2090-91LR, ES3274-75LR, ES3476-77LR, ES373LR, ES411LR, ES423LR, ES844LR

Inquire > Add to Cart >

Specification of Tie Rod End

REF.TKL				REF. NO.				Size Description
								A		B			C			D		E		F
TKL187LR				ES187LR				4.881		1 1/8-12UNF-LR			0.966			1.104		1.102		7/8(14)UNF
TKL2090-91LR				ES2090-91LR				7.362		1 1/4-12LRE			1.078			1.255		1.417		7/8(14)
TKL3274-75LR				ES3274-75LR				5.393		1 1/8-12LRE			1.039			1.187		1.181		7/8(14)UNF
TKL3476-77LR				ES3476-77LR				6.259		1 1/8-12LRE			0.966			1.104		1.102		7/8(14)

TKL373LR				ES373LR				4.448		1-16LRE			0.782			0.900		0.945		3/4(16)
TKL411LR				ES411LR				9.173		1 1/8-12LR			0.966			1.104		1.102		7/8(14)
TKL423LR				ES423LR				5.393		1 1/8-12LR			0.966			1.104		1.102		7/8(14)
TKL844LR				ES844LR				5.393		1 1/8-12LRE			1.078			1.255		-		7/8(14)

Become A Partner?

The Latest Heavy Duty Components to All Your Demands.

Related Tie Rod End

TKLES3030R Tie Rod End

TKLES3030R Tie Rod End

TKLES3030R

TKLES423L Tie Rod End
