Center Support Bearing

TKL NO.
TKL88509, TKL88510, TKL88512A, TKL88508A, TKL88508, TKL88107, TKL5003323
OE NO.
HB88509, HB88510, HB88512A, HB88508A, HB88508, HB88107, 5003323

Specification of Center Support Bearing

TKL NO.	OE NO.	Description
TKL88509	HB88509	Dia Ф45MM, Center Height 69MM, Hole Distance 193.5MM
TKL88510	HB88510	Dia Ф50MM, Center Height 71MM, Hole Distance 193.6MM
TKL88512A	HB88512A	Dia Ф60MM, Center Height 85.7MM, Hole Distance 219MM
TKL88508A	HB88508A	Dia Ф40MM, Center Height 57.1MM, Hole Distance 168.28MM
TKL88508	HB88508	Dia Ф40MM, Center Height 63.5MM, Hole Distance 168.28MM
TKL88107	HB88107	Dia Ф40MM, Center Height 56.5MM, Hole Distance 168.12MM
TKL5003323	5003323	Dia Ф60MM, Center Height 85.58MM, Hole Distance 219MM
